Apr 4, 2019 - Fuse box diagram (location and assignment of electrical fuses and relays) for Chevrolet (Chevy) Impala (2000, 2001, 2002, 2003, 2004, 2005). Fuse box diagram (location and assignment of electrical fuses and relays) for Chevrolet (Chevy) Impala (2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013).

2001 Chevrolet Impala Fuse Diagram for underhood fuse box— top side. AC RLY (CMPR) 10A A/C CMPR Relay DRLJEXT LTS 15A DRL RLY Relay, Headlamp Assembly-Left, and S.E.O. Component EXT LTS 10A Headlamp Assembly-Right FOG RLY 10A FOG LTS Relay F/PMP RLY 15A FUEL PUMP Relay HORN RLY 15A HORNS Relay
